Squeeky rattle in dash

Thread Tools

Old Apr 22, 2011 | 11:58 AM
  #1
PurpleHayzzze's Avatar
Thread Starter
JK Newbie

Joined: Jan 2008
Posts: 40
Likes: 0
From: Mankato, MN
Default Squeeky rattle in dash

I have an extremely annoying squeeky rattle deal going on in my dash.
Symptoms:
-doesn't happen all the time
-seems to do it more often when it's not below 40 degrees F outside.
-occurs on a relatively bumpy road; as in a not smooth surface.
-sounds like it's coming from the direction of the defrost air vents.

Before I tear apart my dash and eff something up, does anyone have any idea what that could be? Has anyone experienced anything similar? And finally, would it be a better idea to just take it into the dealer?
Thanks
Reply
Old Apr 22, 2011 | 12:00 PM
  #2
Captain Wild Thing's Avatar
JK Super Freak

Joined: Jan 2010
Posts: 1,567
Likes: 0
From: LA CA
Default

I also have the same sound haven't found out what is yet
Reply
Old Apr 22, 2011 | 12:12 PM
  #3
scononie's Avatar
JK Enthusiast

Joined: Jan 2008
Posts: 296
Likes: 0
From: Maryland
Default I think I found it...

I think this is the culprit
Attached Thumbnails Click image for larger version

Name:	hamster_powered.jpg
Views:	692
Size:	40.3 KB
ID:	152589
Reply
Old Apr 22, 2011 | 12:26 PM
  #4
bingote's Avatar
JK Freak

Joined: Nov 2010
Posts: 731
Likes: 0
From: Dominican Republic
Default

I know whats happening... We are all driving - very capable - rattle cans!
Reply
Old Apr 22, 2011 | 12:56 PM
  #5
ronjenx's Avatar
JK Jedi Master
15 Year Member

Joined: Feb 2008
Posts: 12,907
Likes: 185
From: Maine
Default

I had an annoying noise from somewhere in the center of the dash.

It turned out to be the A/C lines, where they come through the firewall. They were rubbing on some part of the HVAC unit.

I popped the hood, grabbed the two lines at the firewall, moved them around a little to where they finally came to rest in a slightly different position.

It has been quiet ever since.
Reply
Old Apr 22, 2011 | 01:03 PM
  #6
PurpleHayzzze's Avatar
Thread Starter
JK Newbie

Joined: Jan 2008
Posts: 40
Likes: 0
From: Mankato, MN
Default

Originally Posted by ronjenx
I had an annoying noise from somewhere in the center of the dash.

It turned out to be the A/C lines, where they come through the firewall. They were rubbing on some part of the HVAC unit.

I popped the hood, grabbed the two lines at the firewall, moved them around a little to where they finally came to rest in a slightly different position.

It has been quiet ever since.
Sweet thanks! I'll give it a shot.
Reply
Old Apr 22, 2011 | 01:03 PM
  #7
PurpleHayzzze's Avatar
Thread Starter
JK Newbie

Joined: Jan 2008
Posts: 40
Likes: 0
From: Mankato, MN
Default

Originally Posted by scononie
I think this is the culprit
LOL, that would explain a lot.
Reply

Trending Topics

Old May 5, 2011 | 12:56 PM
  #8
PurpleHayzzze's Avatar
Thread Starter
JK Newbie

Joined: Jan 2008
Posts: 40
Likes: 0
From: Mankato, MN
Default Fixed!

I should report that I did take it in and they found that the HVAC valve was rubbing up against the housing which was causing the squeak. Thank goodness it wasn't a hamster. They apparently put a spacer in there to keep it from ever touching again. Good times
Reply
Old May 5, 2011 | 01:21 PM
  #9
ronjenx's Avatar
JK Jedi Master
15 Year Member

Joined: Feb 2008
Posts: 12,907
Likes: 185
From: Maine
Default

Originally Posted by 97jeeperdrummer
I think I have the same rattle, can you clarify HVAC valve? Thanks!
Post #5 resulted in the same fix.
Reply
Old May 12, 2011 | 06:48 PM
  #10
Nello20's Avatar
JK Newbie

Joined: May 2011
Posts: 1
Likes: 0
From: New York
Default question

How did you get to the A/C lines that go into the firewall?

Originally Posted by ronjenx
I had an annoying noise from somewhere in the center of the dash.

It turned out to be the A/C lines, where they come through the firewall. They were rubbing on some part of the HVAC unit.

I popped the hood, grabbed the two lines at the firewall, moved them around a little to where they finally came to rest in a slightly different position.

It has been quiet ever since.
Reply
