I finally got my homemade custom 2012 dual battery tray back from the powder coater and started installing it in the Jeep.
I also added a little sheet metal to the bracket that holds the wiring harnesses directly under the battery tray (is has exposed wires right next to the catalytic converter and can only get brittle over time with that kind of heat). See first picture for this bracket.
<img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420440"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420441"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420442"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420443"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420444"/>
Next is making all the electrical connections (Winch/ARB dual compressor/Main/Auxillary fused links).
The fuse holders in the second picture are (from left to right). 1. ARB Dual Compressor, 2. Main supply, 3. Blue Sea systems Automatic Charging Relay, 4. Auxillary supply.
The high current fuse for the Winch can be seen in fourth picture.
I'll post more pictures with the final result (hopefully the Jeep will start after this major surgery
).
I also added a little sheet metal to the bracket that holds the wiring harnesses directly under the battery tray (is has exposed wires right next to the catalytic converter and can only get brittle over time with that kind of heat). See first picture for this bracket.
<img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420440"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420441"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420442"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420443"/><img src="https://www.jk-forum.com/forums/attachment.php?attachmentid=420444"/>
Next is making all the electrical connections (Winch/ARB dual compressor/Main/Auxillary fused links).
The fuse holders in the second picture are (from left to right). 1. ARB Dual Compressor, 2. Main supply, 3. Blue Sea systems Automatic Charging Relay, 4. Auxillary supply.
The high current fuse for the Winch can be seen in fourth picture.
I'll post more pictures with the final result (hopefully the Jeep will start after this major surgery
).
